HEEUS

Main Characteristics

Type: Motoryacht
Model: Bering 145
Builder: Bering Yachts
Naval architect: Bering Yachts
Exterior designer: Bering Yachts & SABDES Design
Interior designer: Bering Yachts
Year: 2023
Flag: British Virgin Islands
Classification: Bureau Veritas
LOA (m/ft): 44.20m / 145’
LWL (m/ft): 42.30m / 138’ 7”
Beam (m/ft): 9.7m / 31’ 8”
Draft (m/ft): 2.7m / 8’ 8”
Gross tonnage: 499 GT
Displacement: 498,000 kg
Hull Material: Steel
Superstructure: Aluminum
Decks: Teak
Main engines: 2x Caterpillar C32 ACERT @ 1200 hp each
Max speed: 14.0 knots
Cruising speed: 10.0 knots
Range: 5,000+ nm at 10.0 knots
Guest Accommodations: Sleeps up to 12 guests in 6 cabins
Crew Accommodations:  Sleeps up to 9 crew

Key Features:
- Hybrid Propulsion: Quiet, efficient operation and enhanced maneuverability during docking and low-speed cruising.
- Spacious Interior: 499 GT of volume accommodating up to 12 guests in six cabins, including a main-deck owner's suite.
- Robust Construction: Steel hull and aluminum superstructure built to Bureau Veritas class for long-range durability.
- Advanced Stabilization: ABT TRAC four-fin system operating underway and at anchor for maximum comfort.
- Expansive Sundeck: Features a six-person Jacuzzi, full bar, alfresco dining, outdoor cinema, and weather protection.
- Heavy Lift Capability: 2,721 kg (6,000 lb) SOLAS-rated hydraulic crane for effortless tender launching.
- Long-Range Explorer: 5,000+ nautical mile range at 10 knots with generous fuel and water capacities.

Machinery

• Main Engines: 2x Caterpillar C32 ACERT @ 1200 hp each
• Engine Hours (June 2026): Port – 5,000 hours | Starboard – 5,000 hours
• Shafts: 2x Seatorque
• Tranmission: 2x ZF 5300
• Propellers: 2x 5-blade propellers
• Engine Controls:  Aventix
• Gear Boxes: ZF Gearboxes
• Stabilizers: Four fins ABT TRAC electric stabilization system with “at anchor” stabilization mode
• Thruster: The TRAC AC electric bow 88kW (120 Hp) and stern 59kW (80 Hp) thrusters are driven by VFD motors with frequency-controlled controllers to smoothly change the speed and control the starting current.
• Steering System: DATA electro-hydraulic power steering system
• Engine Ventilation: Dometic
• Oil Change System: Reverso

Generators & Auxiliary Systems

• Generators: 2x Cat C7.1 118 ekW @ 1500rpm – 400VAC 50 Hz
• Generator Hours (June 2026): Port – 10,000 hours | Starboard – 10,000 hours
• Emergency/night generator: CAT C4.4 65 EkW @ 1500rpm – 400VAC 50Hz
• Electricity: 50 Hz 230V AC power standard. 400V 3-phase AC:
• 24V DC power standard
• 24/12V DC electronics power
• Shore Power: A/Sea AC54-3 Power frequency converter 54 KVA
• Batteries: 32x Victron 220 AH AGM batteries, deep cycle, 12 VDC:
• Total capacity is 7,040 Amp Hours
• Victron charger for charging electronics / charging starting and house bank battery from gen or shore power

Tank Capacities

• Gross Tonnage: 499
• Displacement Full Load: 514 metric tons
• Fuel Capacity: 25,265 gallons / 95,600 liters
• Fresh Water Capacity: 3,615 gallons / 13,700 liters
• Grey Water: 1,710 gallons / 6,500 liters
• Black Water: 1,710 gallons / 6,500 liters
• Bilge Water: 300 gallons / 1,150 liters
• Sludge: 300 gallons / 1,150 liters
• Lube Oil: 388 gallons / 1,470 liters
• Used Oil: 388 gallons / 1,470 liters
• Water Makers: 1,902 gallons / 7,200 liters per day
• Day Tank: 2x with total capacity 1,584 gallons / 6,000 liters

Ancillary Equipment

• Air Conditioning: Webasto tropical-specification central chilled water air conditioning system with reverse-cycle heating, fresh air make-up unit, and air handling units throughout.
• A/C Sea Water Pumps: Iwaki Magnet Pump
• Circulation Pumps: Iwaki Magnet Pump
• Air Compressor: Gianneschi
• Fresh Water Purification: UV Bluegio
• Fresh Water Filters: National Marine
• Fresh Water Heaters: Webasto
• Watermaker: 2x Selmar
• Water Heater: Webasto
• Fuel Filters: Racor
• Fuel Separator: Racor
• Rudder Angle Indicator: Furuno
• Fuel Transfer Pumps: Alfa-Laval
• Bilge Pump: Poseidon display bilge pump
• Sewage Treatment System: JETS Vacuum
• Grey Water System: Selmar
• Toilet System: JETS Vacuum
• Under Water Lights: 8x LED underwater lights
• Oil/Water Separator: RWO Viola
• Ventilation: Dometic

Safety & Security Equipment

Lifesaving:

• Lifejackets: 28x Solid Adult lifejackets, 4x Child Lifejackets, 16x Adult Inflatable lifejackets
• 2x 12-person life rafts

Firefighting:

• Fireboy engine room fire alarm and firefighting system
• Siemens central smoke alarm system
• Siemens smoke detector sensor in each room
• Siemens carbon monoxide (CO) sensor in tender garage and battery room
• Fireboy Xintex automatic deployment fire extinguishers in the engine room
• Security System: CCTV

Communication Equipment

• SAT com: KVH TracPhone V7-HTS
• VHF System: Furuno
• Intercom System: Jotron Phontech 3100
• Internet: Starlink
• VSAT: Intellian
• 5G Wi-Fi: Teltonic
• GMDSS: Sailor

Navigation Equipment

• Radar: Furuno FAR-2218B X-Band 12kW
• Magnetic Compass: C-Plath Venus
• GYRO Compass: Simrad
• Auto Pilot: Simrad
• Log: Furuno DS-80 Doppler Speed Log
• Echosounder: Furuno FE-800
• Cartography System: MaxSea TimeZero Professional
• GPS: Furuno GP-170
• Displays: 6x screens
• Monitor: 2x HD Hatteland Display
• AIS: Furuno
• Chart Plotter: Furuno GP-170
• Navtex: Furuno NX-700B
• Wind Instruments: Furuno FI-5001 Wind Transducer with NMEA 2000 converter

Deck Equipment

• Anchors: 2x 260Kg HHP type stainless steel anchors
• Anchor Chains: .5 Shackles Port, 7 Shackles STD
• Winches: 2x DATA DZC 3300 series electric winches with deck foot switches
• Windlasses: DATA
• Capstans: 2x DATA DHC 2200 electric capstans mounted in cockpit
• Passarelle: Electric
• Side Boarding Ladder: Starboard side
• Boat Crane/Davits: Steelhead CT-6000 four function hydraulic yacht crane with remote control:
• Max Weight: 1000kg at full extension
• Spotlights: 2x Luminell
• Jacuzzi: 1x 6-person jacuzzi on the sundeck
• Barbecue: Electric BBQ on flybridge

Audio / Visual Entertainment

• Media streaming throughout vessel through SONOS and Apple TV from personal devices
• Large Smart TVs on Main Salon and Sky lounge (85") with internal and external media access
• Smart TVs in all cabins with internal and external media access
• Drop down movie projector on the sundeck with internal and external media access
• Outside cinema on Sun Deck

Office Equipment

• Computers: 4x Lenovo Thinkpads
• Copier/Printer: HP

Galley & Domestic Equipment

• Cooking Equipment: Electrolux induction hob x4, microwave, 2x sinks, glass washer, island with heat lamps
• Oven: Electrolux convection oven
• Refrigeration/Freezer: 3x walk-in rooms downstairs, currently only 1x fridge available., Fridge and freezer in galley - Electrolux
• Dishwasher: Electrolux in crew mess
• Wine Cellar: Various wine fridges
• Laundry:
• 1x Miele Dryers, 2x Samsung dryers
• 1x Miele Washers, 2 x Samsung washers
• Main Deck Pantry: LiftMotion Dumbwaiter, fridge/freezer drawers, ice maker, glass sanitizer
• Bridge Deck Pantry: Wine/Bar fridge, Dumbwaiter
• Crew Mess: Fridge/Freezer, dishwasher

Special Equipment & Other Features

• HEEUS features a hybrid propulsion system. The propeller is driven by electric motors charged by a bank of batteries. The banks are recharged by high-efficiency, variable-speed DC generators, making docking and mooring easy in the electric mode.
• HEEUS is equipped with a heavy-duty 2,721kg (6,000lbs) SOLAS-rated crane mounted on reinforced steel.

Tenders & Water Sport Equipment

Tenders:

• 1x 32’/10m Buran
• 1x 21’/6.5 Gala aluminum hull – 175hp
• 1x 15’/4.6m Gala aluminum hull – 70hp

Watersports/Equipment:

• 2x Seabobs F5S
• 1x Fliteboard (Efoil)
• 2x Waverunners (Yamaha FX SVHO / Seadoo Spark)
• Wakeboards, waterskis
• Inflatable custom slide
• Inflatable trampoline

Accommodation

GUEST & OWNER: Accommodation for up to 12 guests in 6 adaptable cabins; and up to 9 crew, as follows:

• The huge full beam and luxurious Master Cabin is on the main deck forward with separate office space with wine fridge, large en-suite with bath and shower/steam room, his and her vanities and a large walk-in wardrobe.

• Guest Cabins are situated on lower deck and consist of 4 cabins: 2 doubles, 2 convertible twins, and a smaller cabin (convertible) being used as a flexible cabin for extra staff or suitable to guests.
• Lower deck aft are the two mirrored VIP Cabins with fixed Queen Beds and luxury en-suites and huge natural light from the large windows.
• Forward of them are the 2 mirrored guest cabins with convertible twin beds and assertional pullman berths.
• Forward of this is the 6th cabin which has a door both into the guest areas and crew areas, hence our description above of being usable for extra staff, children or guests.

• Situated on the sundeck is an Outdoor cinema along with a 6-person jacuzzi, bar, dining table and fixed sun loungers. The deck has rain/wind proof covers which can make the sundeck an 'indoor' protected area for those days of not-so-perfect weather. Shaded areas on sundeck aft, flybridge and foredeck with clears for sundeck forward to enclose space from the weather.

CREW:

• Captain’s Cabin on Bridge Deck (double) with Ensuite
• 4/5 x Twin Crew Cabins with Ensuite
