SPIRIT OF RANI

Extra Equipment

• Rig (serviced and partly new 2024): Fractional carbon sloop, keel-stepped, manufactured by Southern Spars. It features a three-spreader rig, carbon/rod standing rigging (rod rigging new 2024), Bartels electric headsail roller reefing, and hydraulic backstay, outhaul, vang, and halyard tension controls (Navtec/B&G).

• Sails (new 2024):

- Mainsail: Fully battened deep-roach, 2 slab reefs, Quantum Fusion sailcloth, 7 carbon battens, and Harken batten car/switchcar.
- Jib: 110% Quantum Fusion sailcloth, with a furling drum below the foredeck.
- Free-flying reacher on a furling system.

• Winches: All self-tailing chrome bronze Harken. All blocks and deck gear are Schaeffer mirror-polished stainless steel.

Mechanical Equipment

• Gear Box: KM35A1 Marine Gearbox, 2.6:1 ratio, 8° down drive angle.
• Steering: Direct chain and wire drive, featuring a custom laminated mahogany wheel (1.3m, carbon fibre core) with a wheel brake, and 3.0 revolutions lock to lock with 35° quadrant stops.
• Water Maker: Seafresh H203, fully automatic, 50 litres/hour, 240v AC.
• Air Conditioning: Webasto reverse cycle chilled/warm water system with 8 outlets, 240v AC 50Hz.
• Bow Thruster: Sidepower 90 kgf (7 kW) duo-prop with joystick and on/off control at the helm.

Electrical Systems

• Shore Power: Mastervolt 32A, which includes a 10m shore cable plus a 15m extension, and a 7 kVA galvanic isolator.
• Electricity Output: 230v AC single phase and 24v DC.
• Converter: Mastervolt Sinewave inverter 24/1000W.
• Main Engine Starting Batteries: 1 x Mastervolt AGM 12/90 Ah (90Ah @ 12v starter).
• Service Batteries: 4 x Mastervolt AGM 12/200Ah (400Ah @ 24v, new 2025).

Navigation & Communication

• VHF: Simrad VHF, DSC-enabled (GMDSS), and an Icom waterproof handheld VHF.
• AIS, Depth Sounder, Searchlight, and EPIRB are all installed.
• DSC Controller: Simrad VHF is DSC enabled.
• Autopilot: B&G T2 autopilot with a hydraulic linear drive ram, B&G Hydra G3000 CPU, and B&G Halcyon 2000 compass sensor.
• GPS/Chartplotter: Simrad GPS chartplotter at the chart table with a repeater at the helm. There is also a B&G GFD multi-function display at the chart table and a further monitor in the owner’s cabin.
• Magnetic Compass: A 5-inch Danforth/Rigel compass with light and dimmer.
• Wind Instruments: B&G wind instruments sender at the masthead and B&G 20/20HV multi-function displays (two port and two starboard deckhouse aft).
• Radar: The radar has been removed, but all cables are in place.

Audio Visual Equipment

• Audio Equipment: Bose loudspeaker system throughout all cabins and exterior, and a CD player connected to the Zeuss Navi system.
• Video Equipment: Television with a mast-mounted antenna.

Galley & Laundry Equipment

• Cooking Equipment: Three-burner hob, grill and oven, gimballed mount.
• Refrigerator: Front-loading refrigerator approx. 120L; additional wine cooling fridge approx. 46L.
• Freezer: Polyethylene top-loading freezer approx. 46L.
• Washing Machine: Connection points installed (foredeck anchor hatch).

Deck Equipment

• Anchor Windlass: Lewmar electric windlass with warping/chain gypsy, brake and chain counter, and a wandering handheld control.
• Anchors: Main: 25 kg Delta type; Kedge: 18 kg Fortress type.
• Anchor Chains: Main: 70m x 10mm calibrated chain; Kedge: 10m x 10mm chain + 100m x 20mm multiplait warp.
• Boat Crane & Davits: Yes, they are removable and stored in a locker.
• Passerelle: 1.5m with two pin deck mounts.

Safety & Fire Protection

• Life Jackets: 6 x adult lifejackets with harness, light and whistle.
• Life Rafts: 1 x 8-man SOLAS-approved liferaft with an A survival pack.
• Flares: 1 x SOLAS offshore flare kit and 1 x SOLAS flare container.
• Emergency VHF: Icom waterproof handheld VHF.
• Fire Extinguishers: Multiple portable fire extinguishers as required by IMCI.

Tenders & Toys

• Zodiac 3.6m tender, powered by an 8 HP Yanmar outboard engine.
