Grand Banks 43 Heritage EU

Details

Manufacturer Provided Description
A larger cockpit, expanded staterooms, and a second head are just a few of the many upgrades aboard this successor to the acclaimed Grand Banks 41EU. The 43EU revolutionizes the modern trawler motoryacht concept, offering owners enhanced comfort, performance, and cruising capability. Featuring joystick control, impressive top speeds over 25 knots, and excellent fuel efficiency at displacement speeds, the 43EU delivers more space, better handling, and extended on-water enjoyment than any other yacht in her class.

Specifications

Dimensions

• Maximum Length (Lmax): 15.26 m

• LOA: 13.19 m

• Beam: 4.77 m

• Length Waterline (LWL): 12.17 m

• Maximum Draft: 1.20 m

• Displacement:

• Light: 16,700 kg

• Loaded: 19,000 kg

Engines & Performance

• Engines: Cummins QSB6.7 480HP (2x)

• Engine Type: Inboard, Diesel

• Port Engine Hours: 754.4

• Starboard Engine Hours: 755.3

• Transmission:

• ZF Marine ZF105 S-1, Ratio 1.39:1

• Zeus Pod Drive: Mercury Marine 5-Q4CY64JH, Ratio 2.24

• Propellers: ZF Marine M4, 5-blade

Accommodations

• Cabins: 2

• Forward Master Cabin with double bed

• Port Guest Cabin with twin beds

• Heads/Bathrooms: 2

• Max Persons Onboard: 10

Equipment & Systems

• Generator: Onan 9.5kW 50Hz (1,286.9 hrs)

• Batteries:

• Generator: AGM 80AH

• Engines: 2x 210AH

• Service: 2x 255AH

• Battery Charger: Mastervolt

• Fire Safety: Fireboy Fire System, Seafire CO Detector

Air Conditioning (Tropical Package)

• Dometic Marine Air Units in:

• Forward Master Cabin

• Port Guest Cabin

• Saloon (Port & Starboard)

• Engine Room Ventilation: Livos Tech

• Headroom Blower: Pelonis

Plumbing

• Electric Heads

• Electric Bilge Pump

• Fresh Water Maker (pre-installed piping & wiring)

• Fresh Water Purification System

• Water Heater

Engine Room

• Engine & Generator Seawater Strainers: Croco

• Centek Sea Water Strainers & Mufflers

• Soundproofing Package

Galley & Utility

• Full solid surface countertop

• Miele Electric Cooktop & Microwave

• Vitrifrigo Drawer Fridge (Saloon)

• U-Line Icemaker (Saloon)

• Additional Freezer: Vitrifrigo (Utility Room)

• Additional Refrigerator: Waeco Collmatic (Utility Room)

• Wine Glass Storage Cabinet

Exterior Features

• Davits: Opacmare Model 3030/29 AL12V

• Liferaft: Zodiac Open Sea

• Teak Cockpit & Extended Teak Swim Platform

• Stainless Railings with Canon Launcher Mount

• Swimming Ladder

• Sunbrella Bimini Top

Navigation & Helm (Saloon & Flybridge)

• Raymarine E125 Navigation Plotter

• Raymarine i70 Multi-Function Display (depth, wind, speed)

• Cummins VesselView Engine Display & Interface

• VHF: Raymarine RAY240E

• Ritchie Compass

• Joystick Control with SkyHook Positioning

• GPS Antenna

• Radar: Raymarine Radome

• Electric Windlass: 1,500W
