STEEL

Mechanical Equipment

• Gearboxes: ZF 10150

• Drive Type: ZF

• Main Engines: 2 x CAT 3512B

• Total Power: 2 x 1100 HP / 820 Kw each

• Engine Hours (Port): 10,148 hrs (12.09.2025)

• Engine Hours (Stbd): 10,155 hrs (12.09.2025)

• Generators: 3 x CAT C9 / 175 Kw each

• Generator Hours (Emergency): 18,561 hrs (12.09.2025)

• Generator Hours (Port): 26,784 hrs (12.09.2025)

• Generator Hours (Starboard): 28,288 hrs (12.09.2025)

• Gearboxes: ZF 10150

• Reduction Gears: ZF

• Propellers: 4 x Lips (2 x summer, 2 x winter)

• Flap rudders: Ulstein Hinze Flap Rudder ICE Class 1A

• Rudder Angle: 45

• Steering System: Konsberg

• Stabilizers: 4 Quantum Fins Zero Speed

• Bow Thruster: Schottel 200 Kw

• Stern Thruster: -

• AC/DC Power Supply Unit: -

• AC/DC Universal Power Supply: -

• Shore Power: Atlas Classic III

• Converters: Atlas Classic III

• Batteries:

• 2 x 145 Ah (each engine)

• 2 x Generator (central/stb)

• 4 x Emergency Generator 24 x Service Batteries 224 Ah

• 4 x Emergency Batteries 200 Ah

• 2 x Radio Batteries 110 Ah

• Chargers:

• Mastervolt Charger MASS 24/50 - Engine & Generator Batteries

• Mastervolt Charger MASS 24/30 - Emergency Generator Batteries

• 2 x Mastervolt Charger MASS 24/75 - Service Batteries

• Hydraulics:

• Central HPU in the Engine Room (Hydraulic Power Unit) Koppen & Lethem

• Forward HPU for the jet ski crane

• Tenfjord HPU lazarette unit for steering

• Hydraulic Systems: Tender Davits, Side Platforms, Gangway, Steering, Water Cannons (Pirate Protection)

• Air Conditioning:

• Heinen & Hopman Max. Power 315 kW

• BTU 1.075.410 with 3 Compressors

• Internal circuit with chilled water, cooled by a refrigerant

• Watermakers:

• 2 x HEM 40 Duplex

• 34 m3/day both Watermakers

• Water Filter: 5 micron sediment filters 1 x Charcoal filter

• UV Sterilizer: Aquafine LS HX Series

• Ozone Sanitation:

• 1 x for Black Water Tank

• 1 x for Grey Water Tank

• Toilet System: Water Flush 1000

• Sewage Treatment System: Hamann HL-CONT Electrolysis

• Bilge Separator: Bilge Boy 2.5 gpm (0.57 m3/h)

• Fuel Treatment System: Mahle NFV Filter FTS 1200

• Fuel Polishing system: Alfa Laval

• Fuel Purifier: Alfa Laval

Navigation Equipment

• Magnetic Compass: Cassens & Plath Bravo 170860

• Digital Compass: 2 x B&G H3000

• Repeater: Anschütz 360/10

• Gyro Compass: 2 x Anschütz Standard 22

• Radar Control Unit: Furuno RCU-014

• Automatic Pilot: Raytheon Marine NautoPilot 20X5

• Echo / Log System: Kelvin Hughes GDS101

• AIS: Kelvin Hughes NIS 2002 MkII

• DGPS: 2 x MX420

• Chart Plotter: Wartsila NaviPlanner 4000

• NAVTEX: Furuno NX-700

• Weather Fax: Furuno NX-700

• Weather Station: Furuno NX-700

• Wind Instruments: 2 x B&G H3000

• Searchlights: 2 x Carlisle & Finch Halogen Searchlights

• Sublights: 6 x Underwater Lights Limited 230V, 50 Hz, 150 W

Communication Equipment

• VHF: Kelvin Hughes RT5022

• MF/HF: Sailor CU5100

• SSB: Sailor Iridium

• GSM: Sailor Iridium

• Fleet Broadband System: Sailor Iridium

• Internet:

• Peplink MAX HD1 Dome Pro (5G),

• Peplink Cellular SIM Card Injector (4G),

• Starlink,

• 15 x WiFi Access Point Dual-band 2.4 & 5 Ghz/6 Ghz

• WiFi 6

Deck Equipment

• Anchor Windlass: 2 x MUIR VRC20000 Vertical Windlass

• Capstans: 2 x MUIR VC18000

• Anchors: 2 x Haren-Groningen TW Fully Balanced High Holding Power Anchor 855 kg

• Anchor Chains: 2 x 275m each, 32mm

• Boat Crane & Davits: 2 x Structor (aft) 3000 kg each + 1 x Nautical-Structures EZ-5500-LD-EX-250-310-SOLAS 2495 kg (bow)

• Gangway: J. Van der Velden 625 NB

• Swimming Pool / Jacuzzi (aft): Custom Made 12 tons / water jets / heating / endless pool swim current (adjustable speed)

• Swimming Ladder: Custom Made

• Swim Platform: Custom Made

• Awnings: Custom Made

• Covers: Custom Made

Entertainment Equipment

Main Salon:

• 60" LG OLED TV

• Erard Fixit400 Wall Support for TV

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

• Yamaha RX-A4A Amplifier 11.2 Dolby Atmos 11 x 150W HDMI 4K/8K

• Yamaha R-N600A Amplifier Stereo 100W for Card Corner

Main Dining:

• Yamaha R-N600A Amplifier Stereo 100W for Card Corner

Main Deck Aft:

• 60" LG OLED TV

• Yamaha XAD-QS5400RK 8 Channels Amplifier, Airplay 2, 8 Inputs, Multiroom (Sundeck, Aft, Fwd)

• Apple TV Media Center Gen 4

Private Lounge:

• 43" LG OLED TV

• Erard Fixit400 Wall Support for TV

• Yamaha RX-A2A Home Cinema Amplifier 5.2 Dolby 80W HDMI 4K Airplay 2

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

• SUB Mini Subwoofer

Owner Entrance Lobby:

• 43" LG OLED TV

• Erard Fixit400 Wall Support for TV

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

Owner's Suite:

• 55" LG OLED TV

• Erard Fixit400 Wall Support for TV

• Yamaha RX-A4A Amplifier 11.2 Dolby Atmos 7 x 150W HDMI 4K/8K

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

4 x Twin Cabins:

• 40" LG OLED TV

• Erard Fixit200 Wall Support for TV

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

Crew Mess:

• 32" Smart Led TV

• Erard Fixit200 Wall Support for TV

• Yamaha RX-A2A Home Cinema Amplifier 5.2 Dolby 80W HDMI 4K Airplay 2

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

Captain's Cabin:

• 32" Smart Led TV

• Erard Fixit200 Wall Support for TV

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

Nanny Cabin:

• 32" Smart Led TV

• Erard Fixit200 Wall Support for TV

• Apple TV 4K Media player for movies, TV, Music & Akumendo app

Speakers:

• 6 x Sonance XTR-6R Exterior Speakers (3 x Aft + 3 x Fwd)

• Galley - Owner's Laundry - Chef Cabin - ECR - Laundry: 5 x Yamaha Musicast 21 Airplay 2 Loudspeaker

Miscellaneous & Additional Equipment:

• 20 x Norstone Set of Cables HDMI 4K 2 m

• 70 x Norstone Patch Panel Cables Renewal

• Misc. Equipment - Accessories - Cables

Galley & Laundry Equipment

• 1 x Panasonic Pro II NE-3208 Microwave

• 1 x RATIONAL Commercial Oven

• 1 x MKN Commercial Oven

• 2 x Scott Ceran Stove (4 + 2 Cooking Tops)

• 2 x MKN Deep Fryer

• 1 x MKN BBQ Grill

• 2 x FOSTER Professional Refrigerator

• 1 x FOSTER Professional Freezer

• 1 x Scotsman AC 56 Ice Maker

• 1 x Winterhalter GS 315 Dishwasher

• 1 x Plastic Compactor

• 1 x Kenwood Cooking Chef XL 6.7 L Induction

• 1 x Robot Coupe Ice-cream Machine

• 1 x Bimby WorkWerk Robot

• 1 x Italservice Stresa Electric Slicer

• 1 x Hendi Stand Mixer / Juicer

• 1 x Walk-in Refrigerator

• 1 x Walk-in Freezer

• 3 x Miele (1 x guests + 2 x crew)

• 4 x Miele Dryers (2 x guests + 2 x crew)

Security & Safety Equipment

SAFETY

• SOLAS Rescue Tender

• Kahlenberg 3-6219 M-511A Whistle Control

• BNWAS: Furuno BR530 & Furuno BR560

• 6 x Life Raft (16 pers. each)

• 32 x Life Jackets + 4 x Life Jackets for children

SECURITY

• 16 x NVR CCTV cameras with 4TB Hard Drive

• 1 x Zyxel GS1920-24PoE Switch 24 ports POE

• 10 x Hikvision DS-2CD2523 Fix mini dome camera 4MP IP66 IK10

• 1 x Hikvision DS-2DE2A404 PTZ 360° dome camera 4MP IP66 IK10 for Ext. Aft Deck

• 1 x Hikvision DS-DF8442IXS PTZ 360* dome camera 4K IP67 IK10 for Mast with 1663ZJ ceiling mount short

• 1 x Hikvision DS-1600KIB Touch and detachable network keyboard with Joystick and HDMI Output

FIRE FIGHTING

• 2 Main + 1 Emergency Hi-Fog SPU Nitrogen System with separate circuits for the galley and walk-in fridge

• 10 x Fire Hydrant

• 10 x 18 m Fire Hose

• 26 x Fire Extinguisher (20 x Foam + 6 x CO2)

• 3 x Powder Fire Extinguisher

• 2 x Fire Suits

Tenders & Watersports Equipment

TENDERS

• 1 x Zodiac Hurricane with 2 x Volvo Penta D6, 301 HP each, 702h Port/ 740h Stbd

• 1 x Zodiac Hurricane P560 with 1 x Volvo Penta D3, 160 HP, 365h

WATER SPORTS

• JetSki WaveRunner Yamaha FX160 Cruiser, 160 HP, 43h

• 2 x SeaBob F5S

• 3 x Inflatable Paddles

• 2 x Inflatable Canoe

DIVING

• 2 x Diving Equipment Sets

• 2 x Snorkeling Equipment Sets

Refit Summary 2025

• Full paint job

• New 5G Antenna

• New exterior upholstery
